YT-E Economical medium speed automatic printing slotting die cutting machine
Host and digital display control system, can store common orders, easy to control.
- Commodity name： YT-E Economical medium speed automatic printing slotting die cutting machine
- Product Details
-
Function and characteristic
◆ Host and digital display control system, can store common orders, easy to control.
◆ Electric version hanging, automatic reset, quick single change.
◆ Each unit is equipped with emergency stop switch for safe protective operation.
◆ Clearance adiustment adopts manual adiustment device, more convenient operation.
◆ The whole machine high strength design, spray type circulation lubrication system.
◆ Intemational brands are adopted for electrical components, main switch bearings and start control components.
Technological parameter
Parameter
Unit Model YT-E 922 YT-E 1224 YT-E 1426 YT-E 1628 YT-E 1828 Max. paper size mm 900×2300 1200×2500 1400×2700 1600×2900 1800×2950 Max. printing size mm 900×2200 1200×2400 1400×2600 1600×2800 1800×2850 Skipping feeding size mm 1100×2300 1200×2500 1400×2700 1600×2900 1800×2950 Max. speed mm 150 120 120 100 100 Topping precision Pcs/min ±0.5 ±0.5 ±0.5 ±0.5 ±0.5 Standard plate
thicknessmm 7.2 7.2 7.2 7.2 7.2 Cardboard thickness mm 1.5-11 1.5-11 1.5-11 1.5-11 1.5-11 Min. slotting interval
mm
Normal
150×150Normal
160×160Normal
160×160Normal
165×165Normal
180×180Reverse
220×80Reverse
250×80Reverse
260×80Reverse
280×80Reverse
280×80Max. slotting depth mm 230 300 350 400 450 Min. paper size mm 240×430 320×430 350×430 420×430 450×600
