Automatic(semi-automatic)die-cutting & creasing machine
- Commodity name： Automatic(semi-automatic)die-cutting & creasing machine
- Product Details
-
Technological parameter
Model 1200 1300 1500 1650 Max.paper size 1230×850mm 1320×940mm 1510×1120mm 1670×1250mm Min.paper size 350×450mm 400×500mm 450×550mm 500×550mm Max.die-cutting size 1210×830mm 1300×920mm 1490×1100mm 1650×1200mm The minimum size in mouth 8 8 8 8 Max.die-cutting pressure 300N/cm² 300N/cm² 320N/cm² 350N/cm² Processable paper(mm) Carboard 200-2000g/m² 200-2000g/m² 200-2000g/m² 200-2000g/m² Corrugated paper 8mm(max.thickness) 8mm(max.thickness) 8mm(max.thickness) 8mm(max.thickness) Die cutting precision ±0.1 ±0.1 ±0.1 ±0.1 Max.die-cutting speed 4500 sheets/h 4500 sheets/h 4500 sheets/h 4000 sheets/h Max.feeding pile height 1400mm(above the level) 1400mm(above the level) 1400mm(above the level) 1400mm(above the level) Max.collecting pile height 1200mm(above the level) 1250mm(above the level) 1250mm(above the level) 1300mm(above the level) Total power 11kw 13.5kw 13.5kw 20kw Weight 13T 14.5T 17.5T 21T Imensions 4200×2200×2250mm 4200×2250×2250mm 4200×2300×2250mm 5200×2450×2250mm
