YT Chain Feeder Ink Printing Slotting Machine
- Commodity name： YT Chain Feeder Ink Printing Slotting Machine
- Product Details
-
Function and characteristic
◆ New design of making machine and electricity into the whole.
◆ With beautiful out look, fixed structure, high auto level.
◆ With high precision of process printing, the error chromatic printing is little and easy operation. Sepation by electricity and pneumatic locking up, pneumatic raising plate and auto adjusting ink. Printing phase and slotting phase with 360 degree Phase with electric digital adjustment and no shut down.
◆ Auto lubrication of the areas with oil.
◆ Four knives adjustment, with length, width adjustment upper and lower knife stand, pressing line, cutting knife ruler, pressing paper pole which have combined movement by tools, saving order changing time.
Technological parameter
Model YT-1428 YT-1630 YT-1832 YT-2234 YT-2536 Max.machine speed(pcs/min) 60 60 60 60 60 Max.feeding size(mm) 1450×2900 1660×3100 1800×3400 2200×3600 2500×3800 Max. printing area(mm) 1450×2800 1600×3000 1800×3200 2200×3400 2500×3600 Normal slot Min.feeding size(mm) 380×550 400×550 500×700 550×700 600×700 Linkage Min.feeding size(mm) 380×750 400×750 500×890 550×890 600×890 Max.depth of slotting(mm) 390 430 490 580 660 Printing plate thickness(mm) 6 6 Cardboard thickness(mm) 3、5、7 3、5、7 Slotting width(mm) 7 7 Slotting deepness(mm) 50 50 Registration precision(mm) ≤0.6 ≤0.75 Slotting precision(mm) ≤±1.2 ≤±1.5 Die cutting precision(mm) ≤±1.2 ≤±1.5 Ordinary Min.slotting interval(mm) Normal 125×125×125×125 160×160×160×160 Reverse 215×40×215×40 265×60×265×60 Linkage Min.slotting interval(mm) Normal 180×180×180×180 190×190×190×190 Reverse 270×65×270×65 310×110×310×110
